Imagery/2020_Ortho (ImageServer)

View In: ArcGIS JavaScript ArcGIS Online Map Viewer ArcGIS Earth ArcMap

View Footprint In: ArcGIS Online Map Viewer

Service Description: Ayres Associates provided Jefferson County, Wisconsin with digital, 4-band orthoimagery services in 2020 as part of WROC. The aerial imagery was collected on March 17th, April 5th, 18th, 20th and May 3rd using a Microsoft Vexcel UltraCam Eagle sensor mounted in a fixed-wing aircraft. Aerial imagery was collected to support 0.5 foot ground sample distance (GSD) orthoimagery to meet ASPRS Class II horizontal accuracy specifications at 1"=100' map scale. The 6-inch pixel orthoimagery was produced to meet or exceed 1.4 foot RMSE according to ASPRS Positional Accuracy Standards for Digital Geospatial Data. Resultant orthoimagery was rectified to a DEM created from LiDAR collected in 2019. Orthoimagery was delivered in PLSS section GeoTiff and MrSID tiles and a project-wide MrSID mosaic. The orthoimagery was delivered according to a PLSS section tile schematic. The project area covers approximately 582 square miles. Supplemental Information: The Wisconsin Regional Orthoimagery Consortium (WROC) is a multi-entity group of county members and partners led by regional planning commissions (RPCs) and WROC representatives from Ayres Associates. The goal of the consortium is to build and sustain a multi-participant program to acquire digital orthoimagery and elevation data throughout Wisconsin. Orthoimagery was collected for Jefferson County in 2020 to provide consistent deliverable products and accuracy standards for each of the participating entities.

Name: Imagery/2020_Ortho

Description: Ayres Associates provided Jefferson County, Wisconsin with digital, 4-band orthoimagery services in 2020 as part of WROC. The aerial imagery was collected on March 17th, April 5th, 18th, 20th and May 3rd using a Microsoft Vexcel UltraCam Eagle sensor mounted in a fixed-wing aircraft. Aerial imagery was collected to support 0.5 foot ground sample distance (GSD) orthoimagery to meet ASPRS Class II horizontal accuracy specifications at 1"=100' map scale. The 6-inch pixel orthoimagery was produced to meet or exceed 1.4 foot RMSE according to ASPRS Positional Accuracy Standards for Digital Geospatial Data. Resultant orthoimagery was rectified to a DEM created from LiDAR collected in 2019. Orthoimagery was delivered in PLSS section GeoTiff and MrSID tiles and a project-wide MrSID mosaic. The orthoimagery was delivered according to a PLSS section tile schematic. The project area covers approximately 582 square miles. Supplemental Information: The Wisconsin Regional Orthoimagery Consortium (WROC) is a multi-entity group of county members and partners led by regional planning commissions (RPCs) and WROC representatives from Ayres Associates. The goal of the consortium is to build and sustain a multi-participant program to acquire digital orthoimagery and elevation data throughout Wisconsin. Orthoimagery was collected for Jefferson County in 2020 to provide consistent deliverable products and accuracy standards for each of the participating entities.

Single Fused Map Cache: true

Tile Info:

Height: 256
Width: 256
DPI: 96
Levels of Detail: 9
- Level ID: 0 [ Start Tile, End Tile ]
- Level ID: 1 [ Start Tile, End Tile ]
- Level ID: 2 [ Start Tile, End Tile ]
- Level ID: 3 [ Start Tile, End Tile ]
- Level ID: 4 [ Start Tile, End Tile ]
- Level ID: 5 [ Start Tile, End Tile ]
- Level ID: 6 [ Start Tile, End Tile ]
- Level ID: 7 [ Start Tile, End Tile ]
- Level ID: 8 [ Start Tile, End Tile ]
Format: MIXED
Compression Quality: 75.0
LERC Error: NaN
Origin: X: -1.181213E8
Y: 1.4276129999999997E8
Spatial Reference: PROJCS["NAD_1983_2011_StatePlane_Wisconsin_South_FIPS_4803_Ft_US",GEOGCS["GCS_NAD_1983_2011",DATUM["D_NAD_1983_2011",SPHEROID["GRS_1980",6378137.0,298.257222101]],PRIMEM["Greenwich",0.0],UNIT["Degree",0.0174532925199433]],PROJECTION["Lambert_Conformal_Conic"],PARAMETER["False_Easting",1968500.0],PARAMETER["False_Northing",0.0],PARAMETER["Central_Meridian",-90.0],PARAMETER["Standard_Parallel_1",42.73333333333333],PARAMETER["Standard_Parallel_2",44.06666666666667],PARAMETER["Latitude_Of_Origin",42.0],UNIT["Foot_US",0.3048006096012192]],VERTCS["VCS Name = NAVD88 height - Geoid12B (ftUS)|Datum Name = North American Vertical",VDATUM["North American Vertical Datum 1988"],PARAMETER["Vertical_Shift",0.0],PARAMETER["Direction",1.0],UNIT["US survey foot",1.0]]

Storage Info:

Storage Format: esriMapCacheStorageModeCompactV2
Packet Size: 128

Extent:

Initial Extent:

Full Extent:

Pixel Size X: 0.5

Pixel Size Y: 0.5

Band Count: 5

Pixel Type: U8

RasterFunction Infos: {"rasterFunctionInfos": [{ "name": "None", "description": "", "help": "" }]}

Mensuration Capabilities: Basic

Has Histograms: true

Has Colormap: false

Has Multi Dimensions : false

Rendering Rule:

Min Scale: 0

Max Scale: 0

Min LOD: 0

Max LOD: 7

Copyright Text:

Service Data Type: esriImageServiceDataTypeGeneric

Min Values: 0, 0, 0, 0, 0

Max Values: 208, 199, 176, 190, 255

Mean Values: 104.6589781746, 104.57316468254, 90.625744047619, 113.59126984127, 248.70362103175

Standard Deviation Values: 35.497799559396, 31.5729362222, 26.481098416703, 37.655874496575, 33.059150733278

Object ID Field:

Fields: None

Default Mosaic Method: Center

Allowed Mosaic Methods:

SortField:

SortValue: null

Mosaic Operator: First

Default Compression Quality: 75

Default Resampling Method: Bilinear

Max Record Count: null

Max Image Height: 4100

Max Image Width: 15000

Max Download Image Count: null

Max Mosaic Image Count: null

Allow Raster Function: true

Allow Copy: true

Allow Analysis: true

Allow Compute TiePoints: false

Supports Statistics: false

Supports Advanced Queries: false

Use StandardizedQueries: true

Raster Type Infos:

Has Raster Attribute Table: false

Edit Fields Info: null

Ownership Based AccessControl For Rasters: null

Child Resources: Info Histograms Statistics Key Properties Legend Raster Function Infos

Supported Operations: Export Image Identify Measure Compute Histograms Compute Statistics Histograms Get Samples Compute Class Statistics Query Boundary Compute Pixel Location Compute Angles Validate Project
